2026 Husqvarna TC85 17/14
Motorcycle
TC 85 17/14
With a 17" front wheel and 14" rear wheel, the smaller version of the TC 85 bridges the gap between the TC 65 and the larger TC 85 perfectly. The modern 85 cc 2-stroke engine is designed and built to deliver best-in-class performance, with the power customizable thanks to two pre-set maps. A tailored suspension set-up can be achieved easily using the adjustable WP components, while all riders will benefit from the light and agile chassis on track. An extensive list of race-tested parts from respected brands such as Formula, Galfer, Neken, Pankl, and Twin Air underlines the premium specification of the TC 85.
Specs and Features
Engine
Transmission
6-speed
Cooling
Liquid cooled
Secondary gear ratio
13:46
Starter
Kickstarter
Stroke
48.95 mm
Bore
47 mm
Clutch
Wet, multi-disc clutch, Formula hydraulics
Displacement
84.9 cm³
EMS
Keihin PWK 28
Design
1-cylinder, 2-stroke engine
Chassis
Weight (without fuel)
68 kg
Tank capacity (approx.)
5 l
Wheelbase
1282 mm
Front brake disc diameter
240 mm
Rear brake disc diameter
220 mm
Front brake
Disc brake
Rear brake
Disc brake
Chain
428, Non-sealed
Frame design
Central-tube frame with double-cradle
Front suspension
XACT 43 WP Upside-Down fork, Ø 43 mm
Ground clearance
308 mm
Handlebar
Aluminium, tapered Ø 28/22 mm
Rear suspension
XACT WP PDS mono shock
Seat height
835 mm
Silencer
Aluminium
Steering head angle
63.5 °
Rear subframe design
Aluminium / Polyamide Glass Fiber
Suspension travel (front)
278 mm
Suspension travel (rear)
289 mm
Tyre dimensions (front/rear)
70/100; 90/100
Wheels
1.4 x 17"; 1.6 x 14"
Frame
The frame is constructed from hydro-formed chromium molybdenum steel. This proven material is not only strong, but it offers precise flex and rigidity to maintain the known agility of the TC 85. Inside the frame, the engine is positioned to distribute its weight in the most effective way, which aids stability and leads to easy cornering for all young riders.
WP XACT front forks
State-of-the-art, 43 mm WP XACT AER forks with new settings offer exceptional damping and comfort. Lightweight with 278 mm of travel, the left leg features an air spring that is easily adjusted with a pump to accommodate rider preference, weight, and track conditions.
WP XACT PDS shock
The fully adjustable WP XACT shock offers 289 mm of travel, and is mounted directly to the swingarm using Progressive Damping System (PDS) technology. Working as one with the swingarm, the shock ensures maximum traction and stability.
Subframe
The proven subframe design is a one-piece component made from polyamide glass fiber-reinforced aluminum. This cutting-edge hybrid construction reduces weight with specific rigidity engineered into it for outstanding control and feedback.
